Industrial 8-Port DB-9 RS232 to USB Adapter High-Speed FTDI Chip 921.6Kbps

Industrial 8 port 8 x db-9 RS232 to USB Adapter w/ Metal Case

• Provides 8 RS232 Serial Ports over USB Port
• Provides 8 DSUB-9 Connectors
• Baud Rate from 75 bps to 921.6Kbps
• 512-Byte Deep FIFOs for each Port
• Supports 5,6,7,8 Data Bits
• Odd, Even, Mark, Space, or None parity mode
• Supports 1, 1.5 and 2 Stop Bits
• Supports USB Bus Power
• DC Jack for Optional DC 5V Power Input
• Supports Win98, Me, XP, CE, Win2000, 2003, Vista, Win 7 32/64-Bit

INTRODUCTION

The USBG-8COM-M is a 8S RS232 to USB serial adapter that is designed for PC, thin client, or server to provide instant COM port expansion via the Universal Serial Bus (USB). The USBG-8COM-M provides the scalability to quickly adapt to new USB technologies. Multiple modules can be added to a single USB interface allowing you to add RS232 connectivity as needed. Complete product line offer many choices help you to expand and make your network grow with your requirements.

With the USB Plug-and-Play feature, simply plug in, follow the instructions of Install Wizard, then you are done. You don¡¦t have to deal with Card Slots, I/O address, IRQ jumpers, DMA and others when you are connecting the devices. The System will recognize the device and install the drivers automatically. The USBG-8COM-M is an ideal solution for your expanding applications.

SPECIFICATIONS

USB Port

• Fully compatible with USB1.0 and USB1.1; Forward compatible with USB2.0

Serial Port

Supports 8 DB9-Male UART Serial ports, the key benefits are:

• Data Rate from 75 bps to 921.6Kbps
• 512-Byte Deep FIFOs for each Port
• Supports 5,6,7,8 Data Bits
• Supports 3-wire RS232 Signals (TXD, RXD, GND)
• Odd, Even, Mark, Space, or None parity mode
• Supports 1, 1.5 and 2 Stop Bits
• Rigid Metal Case for Critical Applications

OS Support

• Win 7
• Win 8
• Win 8.1
• Win 10
• Server 2008 R2 and newer editions
• Linux 2.6+
• Mac OSX 10.3 and newer

Power Requirements

Normally Power solely from USB Bus, no external power supply needed.

A +5V DC Jack Input for supports Power over DB9-Male applications.

Form Factor

• 6.83(L) x 3.83(W) x 1.70(H)
• 17.35 x 9.72 x 4.32 cm
