USB Serial

The USB-2CAN-M provides a cost-effective solution for customers to enable communication with CAN bus devices. The solution designed using an ARM Cortex-M0 32-bit micro controller and the USB to serial chip makes it very flexible in handling small burst of CAN frames at a high speed.

The USB-2CAN-SI-M provides a cost-effective solution for customers to enable communication with CAN bus devices. The solution designed with an integrated ARM Cortex-M0 32-bit micro controller and the USB to serial chip makes it very flexible in handling small burst of CAN frames at a high speed.

This 3 ft. USB to Serial adapter is a tool of choice when supporting serial peripherals in newer computers without serial support. Now supported by Windows 11, this is an ideal solution for device support.

• LED activity monitoring
• Full support of RS-232 signals
• USB bus powered
• 3ft. cable connection

Gearmo 2 Port Professional USB 2.0 to Serial Converter FT2232D Chip with Power LED is a great solution when a limited number of serial ports are available.

• Utilizes FT2232D FTDI Chip set
• Automatically configures the additional COM ports
• Plug and Play allows easy installation
• 5ft. Cable Length
• Perfect for connecting serial modems, bar code scanners and others
• Supports Windows 7, 8, 10, and 11, Linux, OSX

• Adds one RS-232, or RS-422, or RS-485 serial port via USB connection.
• Remote Serial Port Sharing: allows remote access to USB serial port regardless of its
  physical location.
• ESD surge protection of 15 KV.
• Monitor LEDs of Power, TxD, RxD indicating power & port status.

Gearmo USB 8 Port Serial RS232 featuring FTDI Chipset with LED Indicators Industrial Version

• 8x DB9 Serial Ports
• Power, RX, TX, LED Indicators
• Surface/Wall and DIN Rail mounting brackets included
• Supports Self Power and Variable Voltage input 9 ~ 48V
• Rugged Metal Chassis

2 Port USB to Serial adapter with RX/TX LED Indicators easily adds 2 standard serial ports to your desktop, laptop or other mobile device and fully supports Windows 10.

• RXD, TXD Status LED Array
• Easy Plug and Play installation
• USB interface: standard Type A female
• Baud rates up to 921.600bps

4 Port USB To Serial Adapter with Rx / TX Indicators easily adds 4 standard serial ports to your desktop, laptop or other mobile device and fully supports Windows 11.

• RXD, TXD Status LED Array
• Easy Plug and Play installation
• USB interface: standard Type A female
• Baud rates up to 921.600bps

2 Port USB-C to Serial adapter with RX/TX LED Indicators easily adds 2 standard serial ports to your desktop, laptop or other mobile device and fully supports Windows 11.

• RXD, TXD Status LED Array
• Easy Plug and Play installation
• USB interface: standard Type-C female
• Baud rates up to 921.600bps

4 Port USB-C to Serial adapter with RX/TX LED Indicators easily adds 4 standard serial ports to your desktop, laptop or other mobile device and fully supports Windows 11.

• RXD, TXD Status LED Array
• Easy Plug and Play installation
• USB interface: standard Type-C female
• Baud rates up to 921.600bps

Add a 4 Port RS232 to USB adapter to your system without having to configure it! The USA-FTDI4x-NUT USB to Serial Adapter protects your devices from ESD and high voltage spikes and other electrical surges that may cause damage.

• Automatic handshaking
• 3ft. cable connection
• Compatible with serial office equipment

RS-232 | 512 Bytes Receive | 512 Bytes Transmit | FTDI

• Expand Your Serial Capabilities: Connect your legacy 9-pin serial device through a USB-A port to add legacy functionality to newer technologies with no serial port connections.
• Safe Connections: Designed with a unique system load reduction feature, the Mini USB to Serial Adapter also offers 15kV ESD protection for connected devices.
• Plug-&-Play: The adapter’s power is drawn from a USB connection for ease of access and is compatible with Windows (up to Win 11), Mac OS, and Linux.
• COM Retention: COM Ports are fully configurable, and after reboots, port assignments are preserved.
• Upstream: 1 USB port, Type A Male Connector
• Downstream: 1 Male DB9, w/ nuts
• LEDs: Power, TX / RX

RS-232 | 512 Bytes Receive | 512 Bytes Transmit | FTDI

• Expand Your Serial Capabilities: Connect your legacy 9-pin serial device through a USB-A port to add legacy functionality to newer technologies with no serial port connections.
• Safe Connections: Designed with a unique system load reduction feature, the Mini USB to Serial Adapter also offers 15kV ESD protection for connected devices.
• Plug-&-Play: The adapter’s power is drawn from a USB connection for ease of access and is compatible with Windows (up to Win 11), Mac OS, and Linux.
• COM Retention: COM Ports are fully configurable, and after reboots, port assignments are preserved.
• Upstream: 1 USB port, Type A Male Connector
• Downstream: 1 Male DB9, w/ nuts
• LEDs: Power, TX / RX

RS-232 | 128 Bytes Receive | 384 Bytes Transmit

• Superior Build Quality: Housed in a rugged steel chassis with built in mountable flanges, the serial adapter hub is perfect for installations in labs, warehouses, or heavy machinery.
• Safe Industrial Connections: Designed for use with Bar Code Scanners, Time Clocks, Label Printers, Point of Sale Terminals, Receipt Printers, and more the USB to Serial Adapter offers 15kV surge protection for connected devices.
• Expand Your Serial Capabilities: Connect 8 legacy 9-pin serial device through a USB-A port to add legacy functionality to newer technologies with no serial port connections.
• COM Retention: COM Ports are fully configurable, and after reboots, port assignments are preserved.
• USB Power: Power is drawn from a USB connection, no bulky power supply or power outlet is required.
• Upstream: 1 USB port, Type B Female Connector
• Downstream: 8 Male DB9, w/ nuts
• LEDs: Power, TX / RX

The GM-1010-B interface converter converts data (TXD,RXD) of RS-232C to TTL/COMS; the TTL electrical level is 0-5V, without an external power supply.

• Works with all communication software, plug & play
• Baudrate: 300bps-115.2Kbps

The GM-10127-B is a port-powered converter with optoelectronic isolation. It complies with RS-232C, RS422, and RS-485 standards; it converts single side RS-232 signal to a balanced differential RS-422 or RS-485 signal.

• Standards: RS-232C/ RS-485/ RS-422 EIA/TIA
• RS-422/485 6 bits terminal block output
• Port protection: RS-232 ±15KV ESD protection;
•  RS-422/485 600W surge protection
• Isolation: 2,500Vrms isolated voltage, continuous 500VDC

Great for RS232 communication between a PC and a device that needs an RS422 or RS485 protocol. The GM-1042E-B converter is compatible with RS-232C, RS-485/422 standards. It converts RS-232 signals into balanced differential RS-485 or RS-422 signals.

• Standards: RS-232C, RS-485/422 EIA/TIA
• Baud rate: 300bps-115.2kbps
• Transmission distance: 1,200m (RS-485/422); 5m (RS-232)

The converter is compatible with RS-232C and RS-485 standards. It converts RS-232 signals into balanced differential RS-485 signals.

• Standards: RS-232C,RS-485 EIA/TIA
• Built in terminal block
• Baud rate: 300BPS-115.2KBPS
• Transmission distance: 1,200m(RS-485), 5m(RS-232)

The GM-1011-B is an RS-232 serial port optoelectronic isolator. It adopts advanced optoelectronic isolation technology, maximally protects RS-232 serial interface devices from bad environment damage, such as ground loop circuit voltage, surge, lightning, ESD, hot-plug and electromagnetic interference, etc.

• Standards: RS-232 & CCITTV.24 asynchronous protocol
• Power: from RS-232(TXD, RTS or DTR)

The GM-1012-B RS-232 extender with optoelectronic isolation allows extending the communication distance between 2 sets of asynchronous RS-232 communication devices to 12km.

• Enables RS-232 transmission distance to 12km
• Isolated voltage: 2,500Vrms impulse or 500VDC

Adopts advanced optoelectronic isolation technology, prevents RS-232 serial interface device damage from a bad environment, such as ground loop circuit voltage, surge, lightning, ESD, hot-plug and electromagnetic interference, etc.

• Transmission mode: asynchronous, full-duplex, full transparent
• Isolated voltage: 2,500Vrms impulse or 500VDC

The GM-1004E-B converts RS-232 signals into balanced differential RS-485 signals. The converter is designed to protect the RS-485 port; with integrated TVS’s (TRANSIENT VOLTAGE SUPPRESSOR).

• Transmission media: twisted-pair or shielded cable
• Baudrate: 300ps-115.2kbps

The GM-1004E-B converts RS-232 signals into balanced differential RS-485 signals. The converter is designed to protect the RS-485 port; with its advanced TVS’s (TRANSIENT VOLTAGE SUPPRESSOR).

• Transmission media: twisted-pair or shielded cable
• Isolation: Isolated voltage 2,500Vrms  500VDC non-stop

The GM-1005A-B converts RS-232 signals into balanced differential RS-422 signals. The transmission distance of RS-232 communication can be extended to 1.2km.

• Transmission media: twisted-pair or shielded cable
• Baud rate: 300bps-115.2kbps

This TB-DB9TO9CAN DB9 female to screw-less 9-pin terminal block adapter provides a convenient and quick solution to convert a DB9 to a 9-pin terminal block for easy and fast writing in CAN Bus. This CAN terminator consists of a 120 Ohm termination resistor.

• Converts the DB9 Male input connected to the Female DB-9 serial port to a terminal block connection for fast easy writing in CAN Bus.
• Supports screw-less wiring with complete RS-422 or RS-485 data signals.
• Extremely compact terminal block connector reduces bulky adapters when needed.
• Easy identification on the adapter for 9 signal pins.
• 120Ohm termination resistor.

This Screw-less terminal block adapter is designed for fast and easy connection from DB9 female to spring clamp terminal block wiring for RS-422 / 485 in one small convenient package featuring ESD protection.

• Converts the DB9 Male input connected to the Female DB-9 serial port to a terminal block connection for fast easy wiring applications.
• Supports screw-less wiring with complete RS-422 or RS-485 data signals.
• Extremely compact terminal block connector reduces bulky adapters when needed.
• Features 30kV ESD Surge Protection to keep your connections safe
• Easy identification on the adapter for 9 signal pins.

RS232 to TTL CMOS Conversion

Conveniently convert to TTL from RS232 with this RS232 to TTL CMOS conversion adapter, it supports standard RS232 signals and does not require any additional power source once connected.

• Provides one RS232 to TTL/CMOS adaption
• Supports 5V and 3.3V Tolerance Signals
• Very compact
• Supports baud rate up to 115.2 Kbps

The GearMo USA-FTDI-A12 is short and to the point!  This 12 inch USB to RS232 serial adapter is the perfect portable connection for serial devices. Making use of the best FTDI Chip, RS232 serial connections are easy and convenient!

• Incorporates FTDI Chip set
• LED indication for power, RX, and TX
• Supports baud rates of up to 1Mbps
• Built-in static and surge protection
• Works with Win 7, 8, 10, and Windows 11

Gearmo USB 4 Port Serial RS232 featuring FTDI Chipset with LED Indicators Industrial Version

New USB 3.2 Gen 1 Industrial 2 port USB hub with a rugged metal chassis includes DIN-Rail and surface mounting brackets. Connect up to two USB devices, 1 serial RS-232 device, and an RJ-45 Ethernet cable.

• Rugged industrial-grade metal case
• USB 3.2 Gen 1 / USB 3.1 / USB 3.0 compliant
• Serial RS-232 DB9 Port FTDI Chipset
• RJ-45 Ethernet Port 10/100/1000
• 15kV ESD Surge Protection
