4 Port USB 3.2 Gen 2 Type-C Hub w/ ESD Surge Protection & LED Indicators
- Protect Your Equipment: The 4-port Type-C hub supports 15KV ESD surge protection for each port to keep your connected peripherals safe from harm.
- Super Fast Speeds: This USB hub is 3.2 Gen 2 compliant, ensuring super-fast + 10Gbps data transfer speeds. It supports super speed plus, super speed, high speed and full speed which enables it to be compatible with USB 3.2 Gen 1 / 2.0 / 1.1.
- Superior Build Quality: Housed in a rugged steel chassis with built in mountable flanges, the 4-port hub is perfect for workstations installations in offices, labs, warehouses, and other industrial applications.
- Upstream: 1 USB-C port, Screw-lock type
- Downstream: 2 USB-A ports, 2 USB-C ports, Screw-lock type
- Power Connector: 2-Pin Terminal Block, DC Barrel Jack 2.1mm ID × 5.5mm OD
- Mounting Options: Wall & Surface
- LED Indicators: Power & Port Status
Model Number: CG-4P31CHUB-M
Documentation & Downloads
4 Port USB 3.2 Gen 2 Type-C Hub w/ ESD Surge Protection & LED Indicators
$148.99
Details
The CG-4P31CHUB-M is a USB3.2 Metal Hub that complies with the Universal Serial Bus (USB) Specifications Revision 3.1 Gen 2 and works up to 10Gbps. It provides 1 USB-C upstream port and 4 downstream facing ports with 2 USB-C and 2 USB-A connectors. With the RISC-like USB controller, it supports simultaneous operation of any combination of SuperSpeed Plus(SS+), SuperSpeed(SS), High-Speed(HS), Full-Speed(FS), and Low-Speed(LS) devices. It is backward compatible with USB1.1, 2.0, USB3.2 Gen 1 legacy devices. The CG-4P31CHUB-M provides a unique self-power mode to work with wide range (+7~24V DC) input DC power from its DC Jack or 2-pin terminal blocks. It supports fast USB charging specifications by turning its downstream ports from a Standard Downstream Port (SDP) into Charging Downstream Port (CDP) or Dedicated Charging Ports (DCP). Since the USB is the most popular external port for the devices to connect to PCs, the CG-4P31CHUB-M provides an ideal solution to expand your USB ports immediately and save your USB investment.
Features:
- Compliant with USB3.2 Gen 2 Specification
- Metal Case with Different Mounting Options for Industrial Critical Applications
- Each Port Supports 15KV (air) ESD Surge Protection
- Upstream Facing Port: USB-C Connector
- Downstream Facing Ports: 2 x USB-C and 2 x USB-A
- Supports Type-C and Type-A Screw-Lock Cables
- Detects Flip-able/Reversible Plugging
- Supports 10Gbps (SS+), 5Gbps (SS), 480Mbps (HS), 12Mbps (FS) and 1.5Mbps (LS) Speed
- Multi Transaction Translators (TT) per Hub
- Built-in Port Status Indicator LED for Each Port
- Supports Wide Range (+7~24V DC) Self-power Input
- Supports BC 1.2: SDP, CDP and DCP modes
- Charges all 4 USB Ports up to 2A Each Simultaneously
- Includes jumper for bus power isolation
Package Contents:
- 4 Port USB 3.2 Gen 2 Type-C Hub
- USB-C to Screw Lock USB-C Cable
- 2-Pin Terminal Block
- Power Adapter
*Surface Mounting screws not included.
Technical Specifications
| UPC | 045079162853 |
|---|---|
| Country of Origin | Taiwan |
| Manufacturer | Coolgear |
| Warranty | One Year |
| Item Length (in) | 5.98 |
| Item Width (in) | 2.35 |
| Item Height (in) | 0.93 |
| Connector(s) | 2-Pin Terminal Block, DC Barrel, USB 3.2/3.x Dual Screw Lock Type A Female, USB 3.2/3.x Dual Screw Lock Type C Female |
| LED Indicators | Port Status, Power |
| Downstream Port Count | 4 |
| Input Voltage | 7 ~ 24V DC |
| OS Support / Compatibility | OS independent - No software or drivers required, Linux, Windows 7, Windows 8, Windows 10, Windows 11, Mac OS |
| ESD Protection | 15kV |
| Max Data Transfer Rate | 10Gbps |
| Downstream Port Type | Type A |
| Upstream Port Count | 1 |
| Upstream Port Type | USB Type C Female |
