ChargeIT! Mini + Data 120W USB Dual Type-C PD Injector
Status: Available
Industrial Grade | +12~24V DC Input | Over Voltage & Current Protection | Surface Mountable
- Simultaneous Data & Charging: Experience charging and data communication between your tablet, phone, or other USB-C device and host. Pass data while delivering power in accordance with USB PD 3.0 standards.
- Quick Charging: Provides up to 120W of combined power to the connected host and device.
- Superior Build Quality: Housed in a rugged metal chassis, the PD injector is perfect for installations in workstations, offices, labs, warehouses, classrooms, heavy machinery, automation equipment, and other industrial applications
- PD Profiles: 5 / 9 / 12 / 15 / 20 *profiles can be custom programed
- Power Connector: 2-Pin Terminal Block
- Mounting Options: Wall & Surface
Product Documentation & Drivers
ChargeIT! Mini + Data 120W USB Dual Type-C PD Injector
Documentation
Introduction:
Introducing the ChargeIT! Mini + Data 120W USB Dual Type-C PD Injector – your solution for seamless power and data integration. This cutting-edge PD injector is equipped with USB-C full PD 3.0 and optional USB 3.2 Gen 1 / Gen 2 dual ports, designed for one-to-host and one-to-device connections. It passes data while delivering power in accordance with USB PD 3.0 standards, boasting two PD 3.0 ports, each capable of delivering up to 60 watts and supporting PD profiles of 5 / 9 / 12 / 15 / 20, all customizable to your needs. With a variable voltage input range of +12~24V and robust TVs and ESD protection on data and CC lines, this injector ensures reliability and adaptability for a wide range of applications. Upgrade your power and data connectivity effortlessly with the ChargeIT! Mini + Data 120W USB Dual Type-C PD Injector.
Features:
- Features 2x PD 3.0 Ports up to 60 Watts each.
- PD profiles 5 / 9 / 12 / 15 / 20.
- Voltage and Current profiles can be custom programed.
- Variable voltage input of +12~24V DC.
- TVs and ESD protection on all Data and CC lines
Package Contents:
- 120W USB Dual Type-C PD Injector
- 1m Single Screw Lock USB-C Cable
- 2-Pin Terminal Block
Sometimes you need a product in a flash and just want to verify an item is in stock. Other times you have a specific question regarding a product, shipping method, or your order. Use the form below and we will help. Please refrain from spam, we only log this information to our database for 24-hours and then it's gone.
Specifications
| Manufacturer: | Coolgear | Warranty: | 1 Year | Availability: | Available |
| Barcode: | 045079164130 | Ship Weight: | 0.38 | Condition: | New |
| Part Number: | CG-CSPD60W-2 | Color: | Black | Length/Size: | -- |
| USB Spec: | USB 3.2 Gen 1 | Max Data Rate: | 5 Gbps | Input Voltage: | 12 ~ 24V DC |
| Upstream Port: | Downstream Port(s): | 2x Type C (Charging) | Screw Lock Compatible: |
Yes |
Specifications
| Manufacturer: | Coolgear |
| Barcode: | 045079164130 |
| Part Number: | CG-CSPD60W-2 |
| Warranty: | 1 Year |
| Ship Weight: | 0.38 |
| Color: | Black |
| Availability: | Available |
| Condition: | New |
| USB Spec: | USB 3.2 Gen 1 |
| Max Data Rate: | 5 Gbps |
| Input Voltage: | 12 ~ 24V DC |
| Upstream Port: | |
| Downstream Port(s): | 2x Type C (Charging) |
| Screw Lock Compatible: |
Yes |
